| Spesifikasi | |
|---|---|
| Model Name | LAPN300 |
| Network Standards | IEEE 802.11n | IEEE 802.11g | IEEE 802.11b |
| Radio Frequency Bands | 2.4 GHz |
| Ports | 1 Gigabit Ethernet Port |
| PoE | 802.3af | 802.3at |
| LEDs | One system LED |
| MIMO | 2x2 |
| Antenna Type | Internal |
| Antenna Gain | 1.8 dBi |
| RF Transmit Power | 802.11b @ 11 Mbps: 21 dBm | 802.11g @ 54 Mbps: 20 dBm | 802.11n @ HT20/HT40 MCS7/15: 19 dBm |
| Radio Frequency Channels | 2.412 to 2.462 GHz; 11 channels |
| Receive Sensitivity | 802.11b @ 11 Mbps: -85 dBm | 802.11g @ 54 Mbps: -70 dBm | 802.11n @ HT20 MCS7/15: -65 dBm | 802.11n @ HT40 MCS7/15: -62 dBm |
| Maximum Power Consumption | 12.5W |
| Dimensions (LxWxH) | 243.08 x 236.98 x 43.69 mm (9.57 x 9.33 x 1.72 in) |
| Weight | 489.88 g (1.08 lb) |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Storage Temperature | -20° to 70°C (-4° to 158°F) |
| Operating Humidity | 10% to 85% (non-condensing) |
| Storage Humidity | 10% to 90% (non-condensing) |
| Mounting | Wall | Ceiling | Desktop |
| Number of VLANs Supported | 9, 1 management VLAN plus 8 VLANs for SSID |
| Security Lock | Kensington Lock Slot |
| Access Control | MAC-Based |
| Management Interface | HTTP | HTTPS | SNMP |
| Regulatory Compliance | FCC, CE, IC | Class B, Wireless |
| Event Notification | Local Log, Remote Syslog, and Email Alert |
| Network Diagnostics | Log, Ping, Packet Capture |
| Warranty and Support | Limited Lifetime |
| 802.1X Supplicant | Yes |
| External Power Amplifier | Yes |
| Isolation of Wireless Clients in the Same SSID | Yes |
| Reset Button | Yes |
| Rogue AP Detection | Yes |
| Scheduler | Yes |
| SSID to VLAN Mapping | Yes |
| Wireless Security | WEP | WPA | 802.1X RADIUS |
| WMM | Yes |
