| Print Method |
24 pins Impact Dot Matrix |
| Print Direction |
Bi-direction with logic seeking |
| Colour |
Black |
| Control Code |
PR2, WNI4915, IBM4722, ESC / P2, ESC / P2 + ESC / MC, IBM PPDS emulation |
| Print Speed |
(PR2 Emulation) 10cpi: 585 cps(ESC / P2, Others) 10cpi: 585 cps |
| High Speed Draft |
(PR2 Emulation) 10cpi: 520 cps(PR2 Emulation) 12cpi: 468 cps(ESC / P2, Others) 10cpi: 520 cps(ESC / P2, Others) 12cpi: 624 cps |
| Draft |
(PR2 Emulation) 10cpi: 390 cps(PR2 Emulation) 12cpi: 390 cps(ESC / P2, Others) 10cpi: 390 cps(ESC / P2, Others) 12cpi: 468 cps(IBM4722) 10cpi: 390 cps |
| NLQ |
(PR2 Emulation) 10cpi: 195 cps(PR2 Emulation) 12cpi: 195 cps(IBM4722) 10cpi: 260 cps |
| Letter Quality |
(PR2 Emulation) 10cpi: 130 cps(PR2 Emulation) 12cpi: 156 cps(ESC / P2, Others) 10cpi: 130 cps(ESC / P2, Others) 12cpi: 156 cps(IBM4722) 10cpi: 130 cps |
| MVBF |
7 million lines |
| MTBF |
12,000 POH |
| Printhead life |
400 million strokes / wire |
| Scan Life |
200,000 scans |
| Print Characteristics Character Sets |
International, PC-437 International |
| Barcode |
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Coda bar (NW-7), Industrial 2 of 5 |
| Paper Path |
Manual Insertion : Front in, Front out / Front in, Rear out |
| Passbook |
(Width) 110 - 241.3 mm(Length) Horizontal: 127 - 220 mm, Vertical: 85 - 220 mm(Thickness) Maximum: 2.6 mm, Cover Page: 0.2 - 0.5 mm, Each Page: 0.1 - 0.15 mm |
| Cut Sheet Size |
(Width) 65 - 245 mm(Length) 67 - 297 mm(Thickness) Single Sheet: 0.065 - 0.19 mm, Multi Part: 0.12 - 0.53 mm |
| Line Spacing |
4.23 mm |
| Multipart Copy Capability |
1 original + 6 copies |
| Supported OS |
Windows 2000 / Me /XP / Vista / 7 / 8 / 8.1 / 10 |
| Dimensions (W x D x H) |
384 x 280 x 203 mm |
| Weight |
8.0kg |
| Interface |
Bi-directional parallel interface (IEEE-1284 nibble mode supported), Serial I/F, High Speed USB 2.0 |
| Printable Columns |
Pitch : 10 cpi: 94 cpl, 12 cpi: 112 cpl |
| Warranty |
1 Years |
