| Spesifikasi | |
|---|---|
| Output power capacity | 10.0kWatts / 10.0kVA |
| Nominal Output Voltage | 230V |
| Max Configurable Power (Watts) | 10.0kWatts / 10.0kVA |
| Nominal Battery Voltage | +/-192 V (split battery referenced to neutral) |
| Control panel | Multi-function LCD status and control console |
| Interface Port(s) | RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB |
| Output Voltage Distortion | Less than 2% |
| Other Output Voltages | 220, 240 |
| Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz |
| Other Input Voltages | 220, 240, 380, 415 |
| Typical recharge time | 1.5hour(s) |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Load Crest Factor | 3;1 |
| Waveform type | Sine wave |
| Topology | Double Conversion Online |
| Bypass | Internal Bypass (Automatic and Manual) |
| Input frequency | 40 - 70 Hz (auto sensing) |
| Nominal Input Voltage | 230V, 400V 3PH |
| Output Connections | (6) IEC 320 C13 (Battery Backup) | (4) IEC 320 C19 (Battery Backup) | (1) Hard Wire 3-wire (H N + G) (Battery Backup) | (3) IEC Jumpers (Battery Backup) |
| Input Connections | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G) |
| Input voltage adjustable range for mains operation | 100 - 275 (half load), 173 - 476 (half load)V |
| Input voltage range for main operations | 160 - 275V |
| Audible Alarm | Audible and visible alarms prioritized by severity |
